Manual Bottle Cap Press

Quick, efficient and adaptable manual capping solution for bottles, ideal for small-scale and flexible production environments.

Product details

  • Manual, Efficient Bottle Capping
    The Manual Bottle Cap Press is a bench-top, hand-operated, spring-loaded capping machine designed for reliable fixing of press-on caps. Its simple mechanical operation makes it well suited to small-scale and flexible production environments where speed, control and consistency are required.
  • Adaptable for Press-On Caps & Containers
    The cap press enables secure fitting of press-on lids and caps to a wide variety of container types. A coarse height adjustment combined with a fine adjustable stop allows accurate and repeatable pressing, while an adjustable bottle-positioning vee ensures the container is correctly aligned beneath the press pad.
  • Interchangeable Press Pads
    The standard press pad is a 50 mm diameter flat press. Interchangeable, specially shaped press pads can be manufactured to suit containers with shaped or contoured tops, providing additional flexibility across different product ranges.
  • Adjustable Design for Different Bottle Sizes
    The machine features adjustable height and depth settings to accommodate bottles ranging from 21–85 mm in diameter and up to 240 mm in height, supporting a wide range of bottle formats.
  • Compact, Durable Benchtop Construction
    Its compact bench-top format conserves valuable workspace while delivering long-term reliability. The main construction materials are stainless steel and anodised aluminium alloy, ensuring durability and minimal maintenance requirements.
  • Simple, Operator-Friendly Use
    Designed for ease of use, the Manual Bottle Cap Press is quick to set up and intuitive to operate. Consistent results can be achieved with minimal operator training, making it ideal for short production runs or frequently changing formats.

Technical specifications

Specification
Typical Product Output per Hour 1000 per hour
Machine Height  Max 585 mm depending on height setting
Base Plate Width  200 mm
Base Plate Hepth 250 mm
Machine Weight 10 kg
Cap Range Pressed on caps
Bottle Size 21 to 85 mm diameter, up to 240 mm high
Operation Manually operated with 3:1 mechanical advantage
Manual lever‑operated benchtop vial capping machine with adjustable spring mechanism and metal frame, designed for precise sealing of glass vials and small containers in laboratory and pharmaceutical applications.
Close‑up of a benchtop bottle capping machine pressing a child‑resistant safety cap onto a small plastic bottle, used in pharmaceutical and laboratory packaging for secure sealing and compliance.
Close‑up of a benchtop bottle capping machine securing a white plastic cap onto a small container, with gloved laboratory hands guiding the bottle during pharmaceutical or laboratory packaging and sealing process.
Gloved laboratory hands tightening a tamper‑evident cap onto a small plastic bottle, demonstrating secure sealing and packaging of pharmaceutical or laboratory samples.

Simple, Low-Maintenance Design

The Manual Bottle Cap Press can be cleaned using IPA or ethanol-based cleaning agents.

Why Choose Adelphi

  • Proudly Trusted Worldwide Since 1947

    With decades of experience and installations in over 100 countries, Adelphi is a trusted name.

  • End-to-End Project Management

    From concept to delivery, Adelphi provides complete project oversight. Ensuring a seamless operation.

  • Custom Solutions for Every Industry

    Whether you’re filling pharmaceuticals, cosmetics or food products, our products can be tailored to you.

  • British Manufacturing Excellence

    Our equipment upholds the highest standards of quality, craftsmanship & engineering integrity.

FAQ's

  • What is the Manual Bottle Cap Press used for?

    The Manual Bottle Cap Press is a bench-top, hand-operated capping machine designed for the quick and secure application of press-on lids and caps to both glass and plastic bottles. It’s ideal for laboratories, pilot plants and small-scale production environments requiring efficient, consistent capping performance.

  • How many bottles can the Manual Bottle Cap Press handle per hour?

    This compact capping machine achieves an impressive output of up to 1,000 containers per hour, enabling fast, efficient production while maintaining consistent sealing quality across every batch.

  • Is the height and depth adjustable?

    Yes. The unit features fully adjustable height and depth settings, allowing operators to easily adapt the machine for different bottle sizes, cap types and product ranges. Offering maximum flexibility for varied production runs.

  • Is the Manual Bottle Cap Press suitable for GMP or cleanroom environments?

    Yes. Its compact, easy-to-clean design and manual operation make it well-suited to cleanroom and GMP-compliant environments, where reliability and hygiene are essential.

  • What types of containers can the Manual Bottle Cap Press accommodate?

    The machine is suitable for both glass and plastic bottles, making it ideal for pharmaceutical, cosmetic, beverage, and laboratory products. It can handle bottle diameters up to 100 mm and heights up to 240 mm.
